Digital Multimeters

    Professional Electrical Measurement Solutions

    6000 counts LCD

    MTX 203

    Basic Digital Multimeter

    The MTX 203 provides essential electrical measurement capabilities in a compact, user-friendly package. Perfect for basic electrical testing and troubleshooting with reliable performance.

    Voltage Range

    1000V AC/DC

    Accuracy

    ±0.5%

    carousel slide 1
    carousel slide 2

    Key Features

    Display: 6000 counts monochrome digital display with blue backlighting
    Audible continuity & Diode test
    VLowZ, HOLD, NCV
    Min, Max values
    IP 54 protection rating
    Auto power-off function

    Applications

    Basic electrical testing and troubleshooting
    Residential electrical work
    Educational and training purposes
    Field service and maintenance
    Electronics repair and diagnostics
    Automotive electrical testing

    Technical Specifications

    Type:TRMS AC digital multimeter, 6,000 counts
    Voltage measurement:AC 0.6 V to 750 V (±0.5% + 4D),DC 0.6 V to 1,000 V (±0.2% + 2D)
    Current measurement:AC 10 μA to 10 A (±0.5% + 5D)
    Resistance:1 Ω to 60 MΩ (±0.5% + 5D)
    Capacitance:1 nF to 100 mF (±2% + 5D)
    Frequency/Duty cycle:2 Hz to 1 kHz (±0.1% + 3D)
    Temperature:-55 °C to +1,200 °C (K thermocouple)
    Functions:Min/Max, ΔREL, VLowZ, HOLD, NCV (non-contact voltage), Continuity (beep < 50 Ω), Diode test
    Display:Monochrome 6,000-count LCD, backlit, red warning at 230 V (NCV)
    Protection:IP54, IEC 61010-2-033, 600 V CAT III
    Power supply:2 × 1.5 V AA (LR6) batteries
    Dimensions / Weight:170 × 80 × 50 mm / 320 g
    Other features:Torch light, shockproof magnetized sheath, MultiFIX compatible
