Earth Loop Testing
CA 6417
Clamp-On Earth Loop Tester
Non-invasive clamp-on tester for fast, safe earth resistance measurement without disconnecting the ground system. Advanced technology for reliable testing.
Safety Rating
CAT III 300V
Range
0.01Ω to 1200Ω
Key Features
Clamp-on measurement for non-invasive testing
Automatic self-calibration
Large LCD display with backlight
Measures earth resistance and leakage current
Memory for up to 300 measurements
Alarm function for threshold monitoring
Applications
Ground system verification
Industrial plant maintenance
Lightning protection system testing
Utility and substation testing
Electrical installation verification
Equipment grounding assessment
Technical Specifications
Loop resistance:0.01 Ω to 1,500 Ω
Loop inductance:10 μH to 500 μH
Leakage current measurement:0.2 mA to 40 A
Ground voltage measurement:0.1 V to 75 V
Frequency:Measurement at 2,083 Hz, transposition at 50/60/128/2083 Hz
Display:OLED, 48 × 39 mm active area, 152 segments, wide viewing angle
Jaw opening:Ø 35 mm
Memory:2,000 measurements with time/date stamping
Communication:Bluetooth (class 2), compatible with DataView® software
Alarms:Programmable on resistance (Ω), current (A), and voltage (V)
Safety:IEC 61010, 600 V CAT IV
Protection:IP40
Power supply:4 × AA (LR6) alkaline or NiMH batteries
Battery life:~1,440 measurements (30 s each)
Dimensions / Weight:262 × 95 × 55 mm / ~935 g (with batteries)
