Thermal Imagers

    Professional Thermal Imaging Solutions

    1280 × 1024 IR Resolution

    TCC 812K

    Ultra-High Res Camcorder

    Ultra-high resolution thermal camcorder representing the pinnacle of thermal imaging technology for the most demanding applications.

    IR Resolution

    1280 × 1024

    Accuracy

    ±2°C, ±2%

    Temperature Range

    -20°C to 1200°C

    carousel slide 1
    carousel slide 2

    Key Features

    IR Resolution: 1280 × 1024 (1,310,720 pixels)
    Ultra-high resolution video
    Temperature Range: -20°C to 1200°C
    Accuracy: ±2°C, ±2%
    State-of-the-art technology
    NETD: < 20 mK

    Applications

    Research and development
    Scientific applications
    High-end industrial processes
    Quality assurance
    Advanced diagnostics
    Professional documentation

    Technical Specifications

    IR Resolution:1280 × 1024
    SuperIR Resolution:2560 × 2048
    Temperature Range:-40°C to 2200°C
    Accuracy:±1°C, ±1%
    FOV:Multiple lenses – L8: 7.9° × 6.3°, L12: 12° × 9.6°, L25: 25° × 20°, L50: 50° × 40°
    NETD:< 20 mK
    Focus:Laser AF / Continuous AF / Manual / Touch AF
    Min Focus:L8 – 5 m, L12 – 1.65 m, L25 – 0.3 m, L50 – 0.2 m
    Image Frequency:30 Hz
    Display:1920 × 1080, 5.1" OLED touchscreen
    Battery:~4 hours (interchangeable)
    Memory:128 GB SD card (30,000 images, 130 hrs video)
