Thermal Imagers
Professional Thermal Imaging Solutions
192 × 144 IR Resolution
TC 3151
Professional Thermal Imager
Professional thermal imager with micro SD storage and advanced measurement capabilities for demanding applications.
IR Resolution
192 × 144
Accuracy
±2°C, ±2%
Temperature Range
-20°C to 550°C
Key Features
IR Resolution: 192 × 144 (27,648 pixels)
SuperIR Resolution: 384 × 288
Temperature Range: -20°C to 550°C
Accuracy: ±2°C, ±2%
Field of View (FOV): 37.2° × 27.8°
NETD: < 40 mK
Applications
Industrial maintenance
Professional inspections
Research applications
Quality control
Predictive maintenance
Advanced diagnostics
Technical Specifications
IR Resolution:192 × 144
SuperIR Resolution:384 × 288
Temperature Range:-20°C to 550°C
Accuracy:±2°C, ±2%
FOV:37.2° × 27.8°
NETD:< 40 mK
Focus:Fixed, minimum distance 0.5 m
Image Frequency:25 Hz
Display:640 × 480, 3.5" LCD touchscreen
Image Modes:Thermal / Visual / Fusion / PIP / Blending
Battery:~6 hours (interchangeable)
Memory:32 GB Micro SD (60,000 images, 150 hrs video)
